LP-O-5403 RGBW
-
PRODUCT INFO
LED54x3W RGBW Waterproof Par Light
● Voltage:AC90 – 250V
● Frenquency:50-60Hz
● Power: 250W
●Lamp:54x3W RGBW
● Lens: 25°
● Rate:IP65
● Control channel: 4/8 CH
● Control model:DMX 512,master/slave,sound-activated,auto-running with built in programs
●Size:35x35x40cm
●G.W:11kgs
|
DMX8CH Mode Channel | ||
|
number |
Function Description |
|
|
0-255 |
General Dimmer |
|
|
0 |
Red off |
|
|
1-255 |
Red ,from dark to light |
|
|
0 |
Green off |
|
|
1-255 |
Green ,from dark to light |
|
|
0 |
Blue off |
|
|
1-255 |
Blue ,from dark to light |
|
|
0 |
white off |
|
|
1-255 |
Dimmer ,from dark to light |
|
|
0-255 |
Strobe from slow to fast |
|
|
0-255 |
Speed from slow to fast |
|
|
0-50 |
CH 1-CH6 on |
|
|
51-100 |
Color choosing process |
|
|
101-150 |
Gradual change process |
|
|
151-200 |
Pulse change process |
|
|
201-250 |
Change process |
|
|
251-255 |
Sound-activation |
|
